Capacity:

• 10,000 Liters algae culture

Production:

• Biomass produced annually: ~1,000 kg (~2,200 lbs)

Dimensions:

• Length: 40 meters
• Width: 5 meters
• Depth: 5 cm

Power requirements:

• 110W, 60 RPM motor
• Runs on 110V

Main materials:

• Majority of platform is made of 2 sheets of polyethylene welded together
• Metal propulsion system to stir culture

Process:

• Successful cultivation of Nannochloris and Isochrysis
• Achieves high density due to short light path
• Currently used with semi-continuous harvest (~60% of culture every 6 days) but could be continuous

Delivery:

• Metal propulsion system (package is 3 meter long tube)
• Polyethylene packed in a crate
• Small accessories
